Anti Scald Valve ½? Female for Shower and Eyewash Systems

Short Description:

This anti-scald valve is designed to automatically regulate water temperature in shower and eyewash systems. It ensures that the water does not exceed safe temperatures, providing protection against scalding.

Features:

• Temperature activated valve
• Automatically bleeds water to prevent scalding
• Protected with anti-corrosive Polyamide 11 coating
• Good resistance to acids, bases, seawater, and oils


Specifications

• Connection: ½? Female
• Water inlet pressure: Recommended 2 bar with a maximum of 4 bar (Operation not affected by pressure variations) - please notify us prior to ordering if your water pressure is below 1.5 bar.
• Water supply temperature: 80°C maximum
• Maximum opening temperature: 40.5°C
• Fully closed temperature: 35°C

Benefits:

• Enhances safety by preventing scalding
• Durable coating increases longevity
• Easy installation with standard connection

Use Cases:

• Shower systems
• Eyewash stations

FAQ:

Q: What is the maximum water supply temperature?
A: The maximum water supply temperature is 80°C.

Q: What is the recommended water inlet pressure?
A: The recommended water inlet pressure is 2 bar, with a maximum of 4 bar.
